Introduction

This essential oil extraction system employs steam or water-based distillation for efficient extraction. The process involves either direct steam injection or the addition of water into the extraction vessel, followed by heating and distillation. The complete system comprises key components including extraction vessels, condensers, oil-water separators, coolers, product tanks, filtration units, steam boilers, vacuum pumps, and integrated piping. All materials in contact with the product are constructed from SS304 or SS316 stainless steel, ensuring food-grade quality and long-term durability.

Steam distillation remains the preferred technology for obtaining essential oils from plants due to its affordability, efficiency, and operational simplicity. Our team specializes in customized extraction solutions and has a proven track record of serving clients worldwide in the natural products industry.

steam extraction device

Features

Low-temperature processing: Prevents decomposition and degradation of heat-sensitive materials by keeping organic compounds below their boiling points.

High separation efficiency: Employs steam azeotropy to effectively isolate target compounds from mixtures.

Simple operation: The system design is straightforward, easy to master, and does not require complex equipment or advanced skills.

Environmentally friendly and safe: Uses steam as the distillation medium, contains no organic solvents, reduces pollution, and minimizes operational risks.

High product purity: Target compounds of high purity can be obtained after condensation and phase separation.

Clients can customize the system based on the type, volume, and specific characteristics of their raw materials. Our expert team collaborates closely with clients through detailed consultation to design tailored solutions and provide competitive quotations. We offer comprehensive global services, including on-site installation, system commissioning, operator training, and ongoing after-sales support.

Main parameter

Capacity	500L to 6000L	Temperature	Less than 100℃, automatic control.
Pressure	Less than 2bar	Material	SS304 / SS316
Thickness of extractor	From 3mm to 12mm	Structure of extractor	Three layers vertical structure
Unloading way	Pneumatic quick open, automatic unloading	Vacuum	Water ring vacuum pump

Model

Model	SD500	SD1000	SD2000	SD3000	SD5000
Total Volume(L)	600	1200	2300	3300	5400
Pressure (bar)	1) Inner pressure is normal pressure 2) Jacket is 3bar
OD of manhole(mm)	300	400	400	400	600
OD of outlet door(mm)	400	600	800	800	1000
Heating area(m²)	2.4	3.1	4.2	5.5	7.1
Cooling area(m²)	3	5	5	8	10
Filtration area(m²)	0.25	0.25	0.25	0.25	0.5
Steam required(kg/H)	245	325	345	645	720
Note	The information above is for reference

Applications

The system is ideal for extracting volatile, heat-stable, and water-immiscible compounds from various plant parts, including:

Plant Flowers & Leaves

Geranium, rose, lemon balm, osmanthus, chamomile, wild chrysanthemum, lavender, wormwood, rosemary, patchouli, wintersweet, vetiver, pagoda tree, moonflower, mint, thyme.

Plant Rhizomes & Wood

Agarwood, ginger, aloe, cloves, sandalwood (via steam distillation for botanical extract extraction).

Plant Fruits & Seeds

Passion fruit, pepper (retaining aroma without pungency or bitterness), castor, star anise, grape seed, lemon.

chrysanthemum

Why Choose Our System?

High Efficiency

Faster extraction cycles coupled with superior oil yield.

Food-Grade Materials

SS304/SS316 construction ensures safety and regulatory compliance.

Global Support

Worldwide installation, training, and maintenance services.

Scalable Solutions

Customizable systems from pilot-scale to full industrial production.
